| 型号 | 层数 | 筛孔尺寸(mm) | 进料粒度(mm) | 处理能力(t/h) | 电机功率(kw) | 电机型号 | 偏心轴 转速 (r/min) | 双振幅(mm) | 筛面倾角(℃) | 外形尺寸(mm) |
| 2YA1237 | 2 | 3-50 | ≤200 | 7.5-80 | 4-15 | Y160L-4/15 | 970 | 8 | 20 | 4010×2250×2660 |
| 3YA1237 | 3 | 3-50 | ≤200 | 7.5-80 | 4-15 | Y160L-4/15 | 970 | 8 | 20 | 4010×2250×3140 |
| 2YA1548 | 2 | 5-50 | ≤400 | 50-208 | 4-15 | Y160L-4/15 | 970 | 8 | 20 | 5120×2590×3060 |
| 3YA1548 | 3 | 5-50 | ≤400 | 50-250 | 4-15 | Y160L-4/15 | 970 | 8 | 20 | 5120×2590×3540 |
| 2YA1848 | 2 | 5-80 | ≤400 | 50-260 | 4-18.5 | Y180M-4/18.5 | 970 | 8 | 20 | 5120×2950×3060 |
| 3YA1848 | 3 | 5-80 | ≤400 | 50-300 | 4-18.5 | Y180M-4/18.5 | 970 | 8 | 20 | 5120×2950×3540 |
| 2YA1860 | 2 | 5-80 | ≤400 | 50-300 | 4-18.5 | Y180M-4/18.5 | 970 | 8 | 20 | 6260×2590×3480 |
| 3YA1860 | 3 | 5-80 | ≤400 | 50-350 | 4-22 | Y180L-4/22 | 970 | 8 | 20 | 6260×2990×3960 |
| 2YA2160 | 2 | 5-150 | ≤400 | 100-500 | 4-22 | Y180L-4/22 | 730 | 6-8 | 20 | 6270×3410×3670 |
| 3YA2160 | 3 | 5-100 | ≤400 | 100-500 | 4-30 | Y200L-4/30 | 730 | 6-8 | 20 | 6270×3470×4100 |
| 2YA2460 | 2 | 5-150 | ≤400 | 150-700 | 4-37 | Y225S-4/37 | 730 | 6-8 | 20 | 6270×3770×3610 |
| 3YA2460 | 3 | 5-150 | ≤400 | 150-700 | 4-37 | Y225S-4/37 | 730 | 6-8 | 20 | 6270×3790×4100 |
